Headpiece
- Flexion: 0 – 5°, Extension: 0 – 23°
- Vertical Elevation: 0 – 6.75” (0 -17 cm)
- Straight Drop & Forward Motion Drop: 0.62” (16 mm) drop height, adjustable tension
- Compound angles possible, locks into position
- Cushions are adjustable in width at front end
- Contoured cushions: 2” thick (0.5” soft foam laminated to 1.5” firm foam)
- Cocking lever & adjustable tension control on right side (when lying prone)
- Paper Hanger, Hold-Down & Tear-Off Bar (One roll of 8.5″ headpiece paper provided)
Prone Arm Rest
- Adjustable position
- Optional Crescent Arm Rest (see Accessories)
Thoracic Drop & Incline
- Drop height of 0.7” (17.5 mm) at front
- Inclines to fixed 30° (7.5” /19 cm) at front. Does not drop in inclined position.
- Cocking lever on one side of table (choice of Right or Left when lying prone)
- Adjustable tension control on one side of table (same side as cocking levers)
- Stainless steel plunger (with compression spring) in high density polyethylene housing
- 1.5″ thick, high resiliency firm foam
- 16” x 20” (41 x 51 cm)
Pelvic Drop
- Drop height of 1.25” (32 mm) at front
- Cocking lever on one side of table (choice of Right or Left when lying prone)
- Adjustable tension control on one side of table (same side as cocking levers)
- Stainless steel plunger (with compression spring) in high density polyethylene housing
- 1.5″ thick, high resiliency firm foam
- 10.5” x 20” (27 x 51 cm)
Caudal Drop
- Drop height of 0.7” (17.5 mm) at front
- Cocking lever on one side of table (Right or Left when lying prone)
- Adjustable tension control on one side of table (same side as cocking levers)
- Stainless steel plunger (with compression spring) in high density polyethylene housing
- 1.5″ thick, high resiliency thick foam
- 20” x 20” (51 x 51 cm)
Ankle Rest Extension
- Adjustable Extension: 0 -11” (0 – 28 cm)
- Locks in any position
- 1.5″ thick, high resiliency firm foam
- 6.5” x 20” (17 x 51 cm)
